DC Controller

Flexible low-voltage control for EC fans and LED lighting.
The KIWI DC Controller range provides smooth 10VDC PWM control for DC circuits, with installer-adjustable minimum and maximum output levels. Choose from standard variable control, advanced timer and High/Low functions, or multi-point press-mech control. Explore the range below to find the right DC controller for your application.

Explore the upgraded range
DC Controller

Product Description

KIWI DC Controllers provide flexible low-voltage control for EC fans, LED lighting and other 10VDC control circuits. The range delivers smooth 120Hz PWM output, with adjustable minimum and maximum levels so the output range can be tailored to each installation.

Choose the controller that suits the application: simple variable control, advanced timer and High/Low operation, or multi-point press-mech control. All models are designed for 10VDC input and provide 0–98% control output.

K001DC — DC Variable Resistor

  • Full-range control
  • Adjustable minimum and maximum limits

K001DCU — DC Universal

  • Full-range control
  • Adjustable minimum and maximum limits
  • Delay OFF Timer, adjustable up to 20 minutes
  • Installer-set High/Low switching levels

K001DCUW — DC Press Mech

  • All K001DCU functions
  • Press mech, push-button or momentary-switch control
  • Multiple remote control points for On, Off, Up and Down functions

Important: This controller is designed for 10VDC input only. Do not connect AC mains.

ENQUIRE ABOUT THIS PRODUCT

Flexible low-voltage control for EC fans and LED lighting.
The KIWI DC Controller range provides smooth 10VDC PWM control for DC circuits, with installer-adjustable minimum and maximum output levels. Choose from standard variable control, advanced timer and High/Low functions, or multi-point press-mech control. Explore the range below to find the right DC controller for your application.

Models

Our DC Controller range is available in the following models:

  • K001DC — DC Variable Resistor
  • K001DCU — DC Universal
  • K001DCUW — DC Press Mech

Applications

  • 10VDC Control Circuits
  • EC Fans
  • LED Lighting
  • 10VDC PWM Variable Control

Benefits

Low-Voltage DC Control

Designed for 10VDC control circuits, with smooth 120Hz PWM output from 0% to 98% of the input voltage.

Installer-Defined Output Range

Adjustable minimum and maximum trimmers allow the control range to be tailored to the connected EC fan, LED lighting or DC application.

Delay OFF Timer

K001DCU and K001DCUW models include an adjustable Delay OFF Timer, with settings from 0 seconds up to 20 minutes.

High/Low Control

K001DCU and K001DCUW models provide installer-set High/Low switching levels, allowing the application to move directly to the selected maximum output level.

Multi-Point Press Control

K001DCUW supports press mechs, push buttons and momentary switches for remote On, Off, Up and Down control from multiple locations.

Fits Common Flush Plates

Adaptors are supplied for PDL 600 Series, PDL 300/Iconic, Generic, HPM and Clipsal flush plates.

Compact Installation

Up to six K001DC controllers can be installed in one flush box.
